Model | NK-6310 |
Throughput | 60 tests/hr |
Assay Items | 5 parts, 28 parameters,2 histograms, 2 scattergrams |
Principle | Tri-angle laser scatter,Flow cytometrymethod, 3D scattergram analysis, Impedancemethodfor RBC and PLT counting, Cyanide-free method for HGB test |
TestMode | CBC+DIFF , CBC |
Parameters | WBC, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-SD, RDW-CV, PLT, MPV, PCT,PDW, P-LCR, P-LCC, NEU%, LYM%, MON%, EOS%,BAS%,NEU#, LYM#, MON#, EOS#, BAS# 4 Research parameter: ALY%, ALY#, IG%, IG# |
Item | WBC RBC HGB PLT |
Linearity range | (0~300.0x10^9)/L (0~8.00x10^12)/L (0~250)g/L (0~3000x10^9)/L |
Carry Over | ≤0.5% ≤0.5% ≤0.5% ≤1.0% |
CV | ≤2.0% ≤1.5% ≤1.5% ≤4.0% |
incubators | integral titanium incubator system |
Storage | 100,000 results including histograms,scattergrams and patient information |
LIS Interface | support HL7 protocol |
Power Supply | AC220V±10% 50/60Hz; 110V±10% 60Hz; 400VA |
Package Size | 730*610*830mm(W*D*H) |
Gross Weight | 80kg |
ReagentPackage Size | 320*320*290mm (W*D*H) |
ReagentGross Weight | 22kg |
